MPN: 02506-001
Axis Communications
AXIS Q1806-LE 02506-001
AXIS Q1806-LE 02506-001
- Free standard shipping to the 48 states and DC
- Ships in 1–2 business days; ground delivery usually 3–5 business days after that (shipping policy)
- 30-day returns (refund policy)
- Quote within 1 business day: request a quote
- Purchase orders and tax-exempt orders accepted; Net 30 available to approved business accounts
20 in stock
Couldn't load pickup availability
Buying more than one?
Send the quantity and we will price it properly. Volume, government and education pricing, purchase orders and tax-exempt orders all handled.
Request a quote on this partOr call 310-360-1245.
- 7331021078499
- 02506-001
Specifications
| Model | Q1806-LE |
|---|---|
| Maximum Video Resolution | 2880 x 1620 |
| Maximum Frame Rate | 90fps |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/1.8" |
| Focal Length | 4.3-137mm |
| Lens Type | Varifocal |
| Optical Zoom | 32.0x |
| Horizontal Field of View | 60-2.3° |
| Vertical Field of View | 39-1.3° |
| Wide Dynamic Range | Yes |
| SD Card Slot | Yes |
| Power over Ethernet (PoE) | Yes |
| Ingress Protection Rating | IP66, IP67 |
| Operating Temperature | -40-60°C |
Specifications for part number 02506-001. Each figure matched the manufacturer's published specifications when we checked on 2026-10-12. Confirm any figure your design depends on against the current datasheet before ordering.
AXIS - CAMERA Q1806-LE (MPN 02506-001) is a network camera in the AXIS - CAMERA surveillance range, supplied by Multioculus to integrators, IT teams, government and education.
Buying this from Multioculus
- Availability is confirmed, not assumed. We check live distributor stock before quoting, so you get a real ship date rather than a guess.
- Volume, government and education pricing. Tell us the quantity and the project and we will price it properly.
- Purchase orders welcome. Tax-exempt orders handled. W-9 and references on request.
- Full manufacturer specifications, datasheets and warranty details available on request - ask and we will send the current documentation for this part.
Request a quote with the part number and quantity, or call 310-360-1245. Request a quote.
